This pump is an aluminum pump with a cast-iron sleeve and roller bearings on both ends of the crankshaft. This pump comes with a 10" tapered shaft flywheel and is set up to be used with a 6-J series poly-groove belt as and has a 6 1/2 inch square bolt pattern from ceter to center of all four mounting pads as shown in the pump picture. This pump is being used as the main replacement pump for DeVilbiss, Porter Cable, Sears Craftsman and DeWalt for thier 3 to 6.5 HP air compressors and is rated from 6 to 12 cfm, with pump rpm ratings set between 600 to 1250 rpm's. For addition information please contact our office Monday thru Friday from 9am to 4pm Central standard time at (***)-673-5707. The pully on this pump is on a tapered shaft and is designed for this pump only and needs to have a 6 J Poly-Groove belt. The 6 J poly-groove belt is a flat belt on on side and has small v's on the other side. Please do not order this pump and think you can change the pully on the pump to fit your application no returns will be allowed for wrong applications. (this posting is the responsibility of the poster) |
