PULLMAX MODEL Z41 HYDRAULIC VERTICAL/HORIZONTAL ANGLE ROLL* Diameter of Rolls: 15-3/4"; Diameter of Shafts: 6-5/8" Minimum Distance Between Lower Roll Centers: 19-1/4" Speed of Rolls: 7.2 RPM; Feed Speed: 29 FPM; (2) Roll Drive EQUIPPED WITH: (1) Set of Standard Rolls; 4-Directional Guide Rolls Hydraulic Adjustment to Guide Rolls & Lower Rolls AC Main (Pump) Drive Motor; Electrical Controls Pendant Push Button Operation CAPACITIES: Angles - Leg Out: 5" x 5" x 1/2" to 60" Minimum Diameter Angles - Leg In : 4" x 4" x 1/2" to 72" Minimum Diameter Smallest Angle - Leg Out: 1-3/4" x 1-3/4" x 1/4" to 24" Min. Dia. Beams on Flanges: 8" x 5-1/4" to 70" Minimum Diameter Channels - Flanges Out: 10" x 2-5/8" to 70" Minimum Diameter Channels - Flanges In: 10" x 2-5/8" to 70" Minimum Diameter Flats: Edge: 5"x3/4" to 50" Min.Dia.; Flat: 8"x1-1/2"x32"Min.Dia. Squares: 2-3/4"x2-3/4" to 32" Min.Dia.; Bar: 3" to 30" Min.Dia. Standard St. Pipe: 4" to 50" Minimum Diameter Approximate Overall Dimensions: 72" L-R x 65" F-B x 65" H Approximate Weight: 12,000 Lbs. Serial Number: (New 1972) P2 F.O.B. Elk Grove, IL - $ 32,500.00 * PRELIMINARY SPECIFICATIONS SUBJECT TO VERIFICATION Email us at M.nichols@dfwind.com Call our Sales Staff at 1-(***)-254-8808 Prices do not include any federal, state or local taxes, which are in addition to the purchase price and must be paid by the Purchaser. Any and all foreign duties and taxes are the responsibility of Purchaser. Unless Purchaser furnishes PMS with a tax exemption certificate, any sales, use, excise, or other similar tax, where applicable, shall also be the responsibility of Purchaser and may, at the election of PMS, be added to the quoted purchase price and invoiced by PMS to Purchaser. The failure of PMS to invoice such taxes does not excuse the Purchaser from responsibility for paying necessary taxes. Some machinery and equipment is located at Fortune 100 Manufacturing Facilities. Most of the machinery and equipment located at these Facilities is disconnected and cannot be seen under power. Unless specifically listed in writing by PMS, all machinery and equipment uses 3 Phase power. 1-(***)-427-3333 (outside US & Canada) Email: M.nichols@dfwind.com (this posting is the responsibility of the poster) |
M.nichols@dfwind.com (Marvin Nichols) for more information. All emails will be forwarded to the poster's actual email address.
