* Lens Colour : Water Clear * Peak Wave Length (nm) : 465 ~ 470 * Forward Voltage (V) : 3.2 ~ 3.8 * Reverse Current (uA) : <=30 * Luminous Intensity Typ Iv (mcd) : Average in 5000 * Life Rating : 100,000 Hours * Viewing Angle : 20 ~ 25 Degree * Absolute Maximum Ratings (Ta=25°C) * Max Power Dissipation : 80mw * Max Continuous Forward Current : 30mA * Max Peak Forward Current : 75mA * Reverse Voltage : 5~6V * Lead Soldering Temperature : 240°C (<5Sec) * Operating Temperature Range : -25°C ~ +85°C * Preservative Temperature Range : -30°C ~ +100°C Luminous Intensity Typ Iv (mcd) Luminous Intensity Typ Iv (mcd) Luminous Intensity Typ Iv (mcd) Luminous Intensity Typ Iv (mcd) (this posting is the responsibility of the poster) |
