AX4510 Evaluation Board for Samsung S3C4510B AX4510 Evaluation Board for Samsung S3C4510B -10/100M Ethernet, USB, 2x RS232, LCD, PS2, Boot Code, ucLinux ... AX4510 EVB for S3C4510B is a platform that is suitable for code development of Samsung's S3C4510B (ARM7TDMI) RISC microcontroller (General ARM) for network applications and general applications. The S3C4510B is based on 16/32-bit ARM7TDMI RISC processor. It offers a configurable 8K-byte unified cache/SRAM and Ethernet controller which reduces total system cost. Important peripheral functions include two HDLC channels with buffer descriptor, two UART channels, 2-channel GDMA, two 32-bit timers, and 18 programmable I/O ports. On-board logic includes an interrupt controller, DRAM /SDRAM controller, and a controller for ROM/SRAM and flash memory. The System Manager includes an internal 32-bit system bus arbiter and an external memory controller. AX4510 EVB consist of S3C4510B, boot Flash, SDRAM, LCD interface, two serial communication ports, ethernet interface, USB interface, PS2 interface, exterior IDE port, JTAG interface and LED. AX4510 EVB provide a high performance and low cost solution for embedded engineers. Ø 16 M bytes SDRAM(2M x 32bit) Ø 10M/100M Ethernet interface connector(RJ45) Ø IDE44 port: for 2.5" hard disk Ø 20-pin JTAG interface connector Ø all the pins of CPU expand out Ø Samples codes and test software (All in source code) Ø ucLinux source tree(porting for this board) - samples code and test software The evaluation board is capable of supporting different kinds of debugging systems, using an ICE interface. (this posting is the responsibility of the poster) |
