Picture 1: What you see above is what you get. Manual is included which is not shown in the photo above. The picture above shows an LCD screen protected by a removable protective film, which you can remove to reveal a crystal clear picture screen when you have installed the visor. Picture 4: The handset comes with a tripod mount to facilitate long term recording of sound level Complies with IEC651& ANSI S1.4 Use this meter to measure noise levels at workplace for OSHA compliance. Frequency range: 31.5Hz to 8.5K Hz Decibel Range: 30 to 130dBA, 35 to 130dBC Bar graph: 50dB scale at 1dB step for monitoring current sound pressure Level ranges: 30-80dB; 50-100dB; 60-110dB; 80-130dB; Over indicate over range: Under indicate less than lower limit of the range AC output: 0.707Vrms at FS output impendence approx 600 DC output: 10mV/dB output impedance approx 100 Microphone: 1/2 inch Electrets Condenser microphone Power supply: 9V (Alkaline battery included or DC Adapter not included) Self calibration time: 10 sec (every turn on) Operating Temperature: 0C to 40C Operating Humidity: 10% to 80%RH Storage Temperature: -10C to 60C Storage Humidity: 10% to 70%RH Weight: 300g(including batteries) Dimensions 265(L)*70(W)*35(H)mm 1) Do not operate the unit in high temperature and high humidity environment. 2) Remove battery from unit if not in use for extended period of time. 3) In windy environment, mount the windscreen / sponge to minimize wind noise interference. 4) Operational environmental also requires: 1 X Heavy Duty Protective case REFUND POLICY / REPLACEMENT POLICY / RETURN POLICY: Thank you for shopping with us. http://eb.kawagebo.net/LGH/PZh/824_SO.jpg (this posting is the responsibility of the poster) |
