TM-22E (Trms) AC Clamp-on Meter are designed and built for indoors use in an environment of pollution degree 2 according to IEC 1010-1 CAT II 1000V, IEC 1010-1 CAT â…¢ 600V and IEC 1010-2-032 CAT III 600V. * Display: 3 1/2 digits LCD with max. reading 1999, plus decimal point, unit symbol indication. * Overload Indication: LCD will show “1†in the left highest position. * Low Battery Indication: Replace battery immediately when LCD displays “ â€. * TM-22E with True RMS measurements * The maximum conductor size is 35mm. * Sampling Rate: 2 times per second for digital display. * Battery type: 9V NEDA 1604 IEC 6F22 JIS 006P x 1pc. * Battery life: about 200 hours. * Operating Temperature & Humidity: 5℃ ~ 40℃,below 80%RH. * Storage Temperature & Humidity: -10℃ ~ 60℃, below 70%RH. * Size : 218x75x43 mm (LxWxH) * Weight : about 335g (including battery) (this posting is the responsibility of the poster) |
