NEW RCM Flo-Gage Flow Meter 1/2-71-R-10-F 3/4" 1-GPM The 7000 series flow meter is a threaded FNPT connection standard. and FBSP parallel threads available on request for Bronze and Monel meters. Solder connections are also available in 1" and 1 1/2" Bronze bodies. The flow meters can be ordered in Bronze, SST and Monel in pipe sizes ranging from 1/4" to 3". C Calibrated for Specific Gravity D Gasketed Case (NEMA 4X, IP66) D2 Gasketed Case w / Condulet (NEMA 4X IP66) F Aluminum Housing w / Plastic Dial Crystal F2 Aluminum Housing w / Glass Dial Crystal H High Pressure Service (400 psig max.) J Peak Flow Indicator (ABS Housing only) K Saturated Steam Service (120 psig max.) T Expanded Temperature Service (-80ºF - 350ºF) V High Viscosity Service (500cps max.) Pressure Max.: 180 psig (12.6 kg/cm²) 400 psig (28.1 kg/cm²) Pressure Min.: 10 psig (0.67 kg/cm²) 10 psig (0.67 kg/cm²) Temp. Max.: 212 ºF (100ºC) 350 ºF (177ºC) Temp. Min.: -30 ºF (-34ºC) -80 ºC (-62ºC) Bellows: Bronze Monel, 316 SST, Inconel Seals: Buna-N Viton, EPR, Teflon Crystal: Polycarbonate Glass, Plastic F Aluminum Housing w / Plastic Dial Crystal If you require more detailed specifications, please contact the manufacturer for technical support. (Worldwide including Hawaii, Alaska, Canada) This warranty excludes consumable goods. Consumable goods are not guaranteed to come with the item unless otherwise noted in the item description. Consumable goods includes: toner, ink cartridges, bulbs, and batteries. All California residents will be charged CA sales tax during the Checkout process. Please click on the links below for answers frequently asked questions about that category. Questions? Check out our Frequently Asked Questions page for detailed answers. Request for return merchandise authorization (RMA) Call us. (Monday-Friday 10AM-6PM PST) Mailing address for money orders and checks Tel: (***) 757-3863 (Toll Free) (this posting is the responsibility of the poster) |
