Rigol DC1062CD Mix mode 60MHz Digital color storage oscilloscope & 16 channel 400MSa/S color logic analyzer You won’t be disappointed for the price you pay for this scope. It's best for today's micontroller related product development, which 16 channel of logic analyzer and 2 channel of 60MHz scope, mix mode complex trigger is possible and design to debug so most difficult to track MCU-analog problem. You can compare all the feature and quality to scope on the market which price 4-5 time higher. With the 60MHz band with, and 400MSa/S/16Channel. It is suitable for everyday development needed. we also have the 100MHz mix mode version, please let us know if you are interested. N time acquisitions, all channels simultaneously, N is selectable from 2, 4, 8, 16, 32, 64, 128 and 256 1M?±2%?in parallel with 15pF±3pF 400V?DC?AC Peak, 1M? input impedance? Time delay between channel (typical) 1Sa/s-400MSa/s (Real-Time), 25GSa/s (Equivalent) 1M samples for single channel, 512K samples for each channel 5ns/div-50s/div, DS1102XX, DS1062XX 10ns/div-50s/div, DS1042XX 20ns/div-50s/div, DS1022XX 1-2-5 Sequence Sample Rate and Delay Time Accuracy ±100ppm (over any ?1ms time interval) Delta Time Measurement Accuracy (Full Bandwidth) Single-shot: ±(1 sample interval+100ppm×reading+0.6 ns) >16 averages: ±(1sample interval+100ppm×reading+0.4 ns) 8-bit resolution, each channel samples simultaneously* ±40V(200mV-5V), ±2V(2mV-100mV) 100MHz(DS1102CD, DS1102C, DS1102MD, DS1102M) 60MHz(DS1062CD, DS1062C, DS1062MD, DS1062M) 40MHz(DS1042CD, DS1042C, DS1042MD, DS1042M) 25MHz(DS1022CD, DS1022C, DS1022MD, DS1022M) 80MHz(DS1102CD, DS1102C, DS1102MD, DS1102M) 60MHz(DS1062CD, DS1062C, DS1062MD, DS1062M) 40MHz(DS1042CD, DS1042C, DS1042MD, DS1042M) 25MHz(DS1022CD, DS1022C, DS1022MD, DS1022M) Selectable Analog Bandwidth Limit (typical) Lower Frequency Limit (AC –3dB) <3.5ns, <5.8ns, <8.7ns, <14ns, On (100M) (60M) (40M) (25M) respectively 2mV/div-5mV/div: ±4% (Sample or Average acquisition mode) 10mV/div-5V/div: ±3% (Sample or Average acquisition mode) DC Measurement Accuracy, Average Acquisition Mode Average of ?16 Waveforms with vertical position at zero: ±(4%×reading+0.1div+1mV) at 2mV/div or 5mV/div ±(3%×reading+0.1div+1mV) at settings 10mV/div-5V/div Average of ?16 Waveforms with vertical position not at zero: ±[3%×(reading+ vertical position)+(1% of vertical position)+0.2div] Add 2mV for settings from 2mV/div to 200 mV/div Add 50mV for settings from 200mV/div to 5V/div Delta Volts Measurement Accuracy (Average Acquisition Mode) Delta Volts between any two averages of ?16 waveforms acquired under same setup and ambient conditions: ±(3%×reading + 0.05 div) ±12 divisions from center of screen Trigger Level Accuracy (typical) applicable for the signal of rising and falling time ?20ns ±(0.3div×V/div)(±4 divisions from center of screen) Normal mode: pre-trigger(262144/ sampling rate), delayed trigger 1s Slow Scan mode: pre-trigger 6div, delayed trigger 6div Rising, Falling, Rising + Falling ?????=?Positive pulse??????=?negative pulse Video standard & line frequency Support standard NTSC ?PAL and SECAM broadcast systems. Line number range: 1-525 (NTSC) and 1-625 (PAL/SECAM) ?????=?Positive slope??????=?negative slope Voltage difference between cursors (?V) Time difference between cursors (?T) Reciprocal of ?T in Hertz (1/?T) Voltage value for Y-axis waveform Time value for Y-axis waveform Cursors are visible for Automatic Measurement Vpp, Vamp, Vmax, Vmin, Vtop, Vbase, Vavg, Vrms, Overshoot, Preshoot, Freq, Period, Rise Time, Fall Time, +Width, -Width, +Duty, -Duty, Delay1?2 , Delay1->2 5.7 in. (145 mm) diagonal TFT Liquid Crystal Display 320 horizontal ×RGB×234 vertical pixels 64K color?DS1000C ?DS1000CD? Mono?DS1000M ?DS1000MD? 100 ~ 240 VACRMS, 45-440Hz, CAT II +35? or below: ?90% relative humidity +35?~ +40?: ?60% relative humidity Non-operating 15,000 m or below http:// /files/DS5000%20User's%20Manual.pdf For warranty parts and service: Full 3 year warranty on this unit by original mfg. Warranty (DS1000 Series Digital Oscilloscopes) RIGOL warrants that the products that it manufactures and sells will be free from within the respective period, RIGOL will provide repair or replacement as described in the complete warranty statement. To arrange for service or obtain a copy of the complete warranty statement, please contact your nearest RIGOL sales and service office. Rigol do not provide any other warranty items except the one being provided by this summary and the warranty statement. The warranty items include but not being subjected to the hint guarantee items related to tradable characteristic and any Rigol will not take any responsibility in cases regarding to indirect, particular and All purchased are final, will replace defective product only. Return package must be in the original packaging, everything must be in new condition. Missing part’s or anything in original contact will not qualify for any refund. Defective item can be exchanged within 7 days of receipt. Replacement and refunds will not be processed until the return item received. (this posting is the responsibility of the poster) |
