Used Machinery and Machine ToolsUsed MachineryUsed Machine ToolsThousands of Used Metalworking and Plastic Machines & New Machine Tools Photos, Full Descriptions and Prices - Fast & Easy * Manual Lathes, Mills, Drills, Saws * Grinders, Hones, Finishing * Ovens, Furnaces & Environmental 6" CNC LATHE, Clausing-Colchester STORM 80 Fa 6" CNC LATHE, Clausing-Colchester STORM 80 Fa CLAUSING/COLCHESTER STORM 80 2Axes CNC Slant Bed Turning Center, S/N T70065, Swing over bed covers ...................... 16.54†Swing over carriage cover .................. 11.02†Max. turning diameter ...................... 6.69†X-axis travel .............................. 6.5†Z-axis travel .............................. 13.78†Carriage inclination ....................... 60º (slant) Spindle center height from floor ........... 34.45†Spindle nose ............................... A2-5 Spindle bore ............................... 2.13†Bar capacity ............................... 1.65†Spindle front bearing internal diameter .... 3.15†Max. spindle speed ......................... 6000 RPM X and Z axis rapid traverse rate ........... 394/591 IPM Turret tool disc diameter .................. 13.39†Tooling type ............................... VDI 3425/30 Turning tool shank dimensions .............. .787†x .787†Max. boring bar diameter ................... 1.26†Max. travel below center line .............. .866†Cross-slide width .......................... 8.39†Width over linear guide ways ............... 7.36†Bed width .................................. 11.97†- GE Fanuc 21T-B CNC CONTROL w/RS232 Port - (26) Turret tool holders with misc. tooling - 3/60/230 Volt electrics with transformers for 3/60/208 Volt input Machine Location: HARRISON, NJ Click Here For More Clausing-Colchester Machines Click Here For More CNC Machines - CNC TURNING CENTERS - CNC LATHES(s) Call Mike at (***) 873-6224 ext 7540 Call Alex at (***) 873-6224 ext 7613 Finance This Equipment For Your Business - Click Here Finance Equipment For Your Business - Click Here * Machinery Values is one of the world's largest machinery dealers, in business since 1971. * New machines are covered under their own warrantees. Details of each warranty can be found within the quotation for all new machines. * Most items in our store are located in our warehouse in Harrison, New Jersey - about 9 miles from New York City. You may inspect any item prior to purchase, under power in most cases, simply by calling and arranging an inspection. There is no charge for this. (this posting is the responsibility of the poster) |
daisy.burton@dfwind.com (Daisy Burton) for more information. All emails will be forwarded to the poster's actual email address.
