UNIVERSAL MODEL FOR INTERMITTENT PILOT, DIRECT SPARK AND HOT SURFACE IGNITION GAS VALVE 24 VOLT, 1/2" INLET X 3/4" OUTLET WITH OPTIONAL 1/2" SIDE OUTLETS with PLUGS, 150,000 BTU CAPACITY. The 720 Series Valves (7200 IPER) are designed for intermitent pilot ignition applications. The 720 IPER Series Valve incorporates a manual valve, pilot valve, dual automatic valves (2), and a main gas pressure regulator. Uni-Kits are factory-set at the 3.5" W.C. for natural gas, but can be converted to L.P. by installing the regulator conversion kit included. The 720 Series Valves are designed for many residential applications such as central heating units, space heaters, wall heaters, boilers, and mobile home furnaces. The 720 series valve has a compact swing radius of only 3-9/16" to enable it to fit a wide range of OEM replacement applications. It also has all the wiring connections, manual selector, and adjustments readily available on top of the control. To prevent unsafe attempts at repair, special screws are used and replacement parts are NOT available. REPLACES FACTORY MODEL 7200IPER. FUNCTIONAL REPLACEMENTS (MAY REQUIRE REWIRING AND/OR REPIPING) FOR THE FOLLOWING: 00027, 13885A, 150103-26-01, 15691-497, 15691-498, 20691-011, 239-39759-01, 239-39759-02, 3452A, 3453A, 3644932, 36449B2, 36449B1, 36C36-304, 36E01-103, 36E01-105, 36E01-106, 36E01-201, 36E01-204, 36E01-205, 36E01-206, 36E01-221, 36E01-222, 36E01-223, 36E01-225, 36E01-226, 36E01-227, 36E01-233, 36E01-238, 36E01-240, 36E01-241, 36E01-243, 36E01-244, 36E01-245, 36E01-247, 36E01-248, 36E01-257, 36E01-305, 36E01-307, 36E01-308, 36E01-310, 36E36-003, 36E36-004, 36E36-1, 36E36-105, 36E36-106, 36E36-2, 36E36-201, 36E36-210, 36E36-216, 36E36-220, 36E36-227, 36E36-230, 36E36-232, 36E36-235, 36E36-237, 36E36-238, 36E36-243, 36E36-244, 36E36-245, 36E36-248, 36E36-252, 36E36-254, 36E36-255, 36E36-256, 36E36-263, 36E36-265, 36E36-266, 36E36-267, 36E36-303, 36E36-304, 36E36-305, 41882, 42046, 506300, 511-044-367, 5H71911C, 5H71912C, 5H71931C, 5H73205B2, 5H73206B, 5H73206B1, 60-42462-01, 60-42462-02, 601011, 601012, 601170, 700-077, 700-C070, 7100DER, 71B-11A-000, 71B-11A-003, 71B-11A-033, 71B-11A-044, 71B-11C-013, 71B-11C-018, 71B-11C-036, 71D-01B-002, 71D-01B-004, 71D-01B-005, 71D-01B-022, 71D-01B-023, 71D-01B-038, 71D-01D-024, 71D-01D-029, 71D-01U-039, 71F-11A-000, 71F-11A-003, 71F-11A-010, 71F-11A-022, 71F-11A-040, 71F-11A-041, 71F-11C-013, 71F-11C-018, 71F-11C-042, 71F-11T-037, 71H-11A-001, 71J-11A-000, 71J-11C-018, 71L-11A-000, 71M-11A-000, 71M-11A-010, 71P-11A-000, 71P-11A-016, 71P-11C-013, 71P-11C-018, 71S-11A-010, 71S-41A-010, 71S-41A-025, 71T-015-019, 71T-01B-004, 71T-01D-031, 71U-41L-020, 71V-11A-000, 720-080, 7200-IPER-LP, 72001PER, 7A5-A8B-044, 7A5-B3G-006, 7A5-D0A-023, 7A5-D6E-041, 7A5-D7D-040, 7A6-A8B-003, 7A6-C3C-017, 7A6-C3C-053, 7B8-A8B-003, 7B8-A8B-054, 7B8-C3C-013, 7C0-A8B-003, 7C0-C3C-017, 7D1-E9C-047, 7D1-E9C-050, 7E2-D5B-029, 7E2-E9C-050, 7E3-E9C-050, 7E4-D5B-048, 7E4-E9C-050, 810-0457, 810-0464, 93G5601, 95P4601, C64235-01, CAEF26CK201, CAEF29CK261, EF32C5194, G53DBG-2, G53DBG-3, G54BBG-1, G54BCG-1, L37-849, PP10085, PP10086, PSI720-079, V00719, V4185A1000, V4185B1008, V4185B1016, V4185B1024, V4225A1002, V4225A1028, V4225A1044, V4225A1051, V4225A1077, V4225B1000, V4225B1018, V4225B1026, V4227A1000, V4227A1018, V4227B1008, V4227B1016, V4249A1004, V4249A1012, V4249A1020, V4297A1005, V4297A1013, V4297A1021, V4297A1039, V4297A1047, V4297A1054, V4298A1004, V4298A1012, V445A1009, V445A1017, V445A1199, V445B1008, V445M1170, V8185A1001, V8185A1019, V8185A1035, V8185B1009, V8185B1017, V8205A2005, V8205A2013, V8205A2021, V8205A2039, V8205A2047, V8247A1000, V8247B1005, V8457A1026, V845A1018, V845A1034, V845A1133, VR400A1016, VR400A1024, VR400A1032, VR4205A1707, VR4205A1715, VR4450M2035, VR4450M2126, VR4450M2159, VR445M1009, VR445M1017, VR8204A2001, VR8204A2027, VR8204A2035, VR8204A2043, VR8204A2050, VR8204A2068, VR8204A2076, VR8204A2084, VR8204A2092, VR8204A2100, VR8204A2118, VR8204A2126, VR8204A2134, VR8204A2142, VR8204A2167, VR8204A2175, VR8204A2183, VR8204A2191, VR8204A2209, VR8204A2217, VR8204A2241, VR8204A2258, VR8204A2266, VR8204A2274, VR8204A2282, VR8204A2803, VR8204A2811, VR8204A2829, VR8204H1014, VR8204H1022, VR8204H1071, VR8204H1089, VR8204M1000, VR8204M1026, VR8204M1042, VR8204M1059, VR8204M1075, VR8204M1091, VR8204M1117, VR8204M1133, VR8204M1141, VR8204M8005, VR8204M8013, VR8205A2008, VR8205A2016, VR8205A2024, VR8205A2032, VR8205A2040, VR8205A2065, VR8205A2073, VR8205A2081, VR8205A2099, VR8205A2123, VR8205A2131, VR8205A2800, VR8205H1011, VR8205H1029, VR8205H1052, VR8304A2501, VR8305M3506, VR8440A2001, VR8440A2019, VR8440A2050, VR8440A2076, VR8440A2084, VR8440A2092, VR8440A2100, VR8440A2118, VR8440A2134, VR8440A2142, VR8440M1000, VR8440M2008, VR8440M2016, VR8440M2024, VR8440M2032, VR8440M2040, VR8440M2057, VR8440M2065, VR8440M2073, VR8440M2081, VR8440M2099, VR844A1002, VR844A1028, VR844A1051, VR844A1085, VR844M1014, VR844M1063, VR844M1170, VR844M1188, VR844M1196, VR844M1220, VR844M1246, VR844M1287, VR844N1003, VR844R1005, VR8450A2000, VR8450A2109, VR8450A2117, VR8450M1017, VR8450M2023, VR8450M2064, VR8450M4045, VR8450M4144, VR8450R6003, VR845M1013, VR884M1006. THE FOLLOWING VALVES HAVE ARE A SLOW OPENING MODEL: 720-070, 720-072, 720-073, FOR L.P. GAS APPLICATIONS: VR844M1162, VR844M1295, (this posting is the responsibility of the poster) |
