THREE PHASE LINE VOLTAGE MONITOR. Fully programmable with LCD diagnostic display. 25-fault memory storage,non-volatile. Identifies front and back side faults. Protects against: voltage unbalance, high/low voltage, phase loss, phase reversal, faulty power, incorrect sequencing and rapid short cycling. Universal voltage operation: 190-630 VAC. VOLTAGE: 190-630 VAC, FREQUENCY: 50/60 Hz, VOLTAGE UNBALANCE: Adjustable: 2-25%, CONTROL: 18-240 VAC, DELAY ON BREAK TIMER: 1-5 minutes, OUTPUT: Relay, SPDT, N.O.: 10 amps, N.C.: 6 amps. REPLACES: Diversified: AC-2020, AC-301, AC-302, Motorsaver: 455, SSAC: QLM/QLV, Time Mark: 265, Wagner/Diversitech: DTP-3, WPC-800, Watsco: EAC-800, EAC-8000, EAC-8002 Click Here for additional information (this posting is the responsibility of the poster) |
