Power Requirements: 115VAC or 230VAC ±50/60Hz Sensor Power Supply: Maximum supply current at Operating Temperature Range: 32°F to 125°F Operating Rate: 150Hz typical input with a minimum Battery Back-Up: Count Hold Minimum: 8 Hours Sensitivity Settings: Used for analog proximity switch to adjust reach. Each input has its own LED Indicators: Turns "ON" when input signal is detected. Each input has its own Input Signals: Analog Sensors: Digital Sensors: Voltage Range: positive + 10 volts Output of sensors must be open Display: 8 digits with 7segments (.4" high) Dimensions: 6.9" wide x 3.9" high x 3.4" deep Housing Material: Epoxy based painted steel * Items have been tested when possible. * Seven day "no questions asked" return policy. * If item does not function as described call 1-(***)-456-6155 for an RMA (Return Merchandise Authorization). (this posting is the responsibility of the poster) |
d.washington@dfwind.com (Dave Washington) for more information. All emails will be forwarded to the poster's actual email address.
