HP 53310A Modulation Domain Analyzer Loaded! HP 53310A Modulation Domain Analyzer Loaded! The 53310A Modulation Domain Analyzer is an easy-to-operate, affordable modulation domain analyzer with an intuitive data display that gives you a direct view of jitter or modulation. Parameters such as peak-to-peak deviation, carrier frequency, and modulation rate are quickly and automatically displayed. Built-in analysis, including automated mean, standard deviation, and probability functions, provides detailed characterization of jitter. In much the same way an oscilloscope provides insight into the dynamics of changing voltage, the 53310A provides insight into changes in frequency or time-interval measurements. Use the 53310A to study frequency drift in electronic equipment; characterize jitter of digital communications systems, peripherals, and mechanical systems; determine frequency hopping performance of an agile transmitter, or measure cellular phone switching from cell to cell. Dual channel with 3rd channel optional Frequency range: channel A (10 Hz to 200 MHz), channel B (10 Hz to 100 MHz), channel C - optional (50 MHz to 2.5 GHz) Time interval measurement range: +20 ns to +1 s Input impedance: 50 ohm or 1 megohm, ac or dc Standard time base accuracy: 10 MHz, <8 X 10-6th 115/230 Vac -25% to +15%; 48 to 66 Hz operation Option 001 High Stability Oven Reference Option 010 Extended measurement memory Excellent Physcial/Excellent Working Guaranteed with 5 day Right of Refusal This unit has been completely tested and pass all self test. It is in excellent working and physical condition. This unit is loaded with Opt 001, 010, and 031. Contact us at a-adams@dfwind.com with any questions. This item is quaranteed with a 5 day right of refusal. In the unlikely event that your unit arrives not as described, it will be replaced at no charge. If there is no exchange unit available, you will be given a full refund. (this posting is the responsibility of the poster) |
