ROFU® MAGNETIC DOOR LOCK 8022 FOR DOUBLE DOORS NEW Holding Force: 1500 lbs.(675 Kg.) per side. Easy Installation: Versatile mounting bracket for new and existing doors and frames. Sensor: Built-in Hall effect crystal affected by door position, voltage input and LED: Red/Green LED door status indicator is attached to magnet housing. Fail Safe: Releases instantly when power is disconnected. No residual magnetism. Fail Alarm: May be released upon activation of fire alarm. Housing: Attractive, heavy duty, anodized extruded aluminum Current Draw: 415 mA at 12 VDC per block Mounting hardware included with unit for outswinging doors. Optional Z-Brackets required for inswinging doors. Magnet Size: 21" x 25/8" x 15/8" (536 x 68 x 42 mm) (LxHxW) Armature Size: 71/4" x 23/8" x 5/8" (190 x 60 x 16 mm) (LxHxW) Door Status and Power Switch ? The magnet contains a built - in "C" Form contact 5 Amps @24V that is activated by power to the lock and contact between the armature plate and the surface of the lock. It indicates that the power is on and the door is closed. This feature can be used for remote door surveillance, indicator lights and interlocks. Please note: One of two pack of screws are missing. There is a dent in one of the corners of the lock. It does not affect in any way the performance of this lock.Please see picture. On top of that, the prices you get, will be some of the best out there too. I will also accept canadian Postal Money Order with the face value in US funds. If for some reason there is a problem please let me know. I will work it out with you. Copyright 2003 - 2007, Unauthorized Duplication Prohibited (this posting is the responsibility of the poster) |
